Collet for PCB drilling machine spindle
$20 – $30PCB drilling machine spindle is a high-precision mechanical sleeve designed to securely clamp drill bits and ensure near-zero run-out during ultra-high-speed drilling operations.
PCB drilling routing machine parts
PCB drilling machine parts include the tool gripper, tool measure instrument, tool pod, pressure foot brush ect for Schmoll drilling routing machine
Showing all 9 results
-
-
Laser Tool measuring for PCB drilling machine
$75 – $100laser tool measuring instrument, such as the DS-5V-M detector, is a non-contact optical system used in PCB drilling machines to rapidly verify tool diameter, compensate for length, and detect breakage with sub-micron precision.
-
Pressure foot brush for PCB routing process
$0.7 – $4pressure foot brush is a specialized ring-shaped assembly of nylon bristles used in the PCB routing process to stabilize panels, provide a vacuum seal for dust extraction, and prevent surface scratches during high-speed spindle operations
-
Pressure foot cup for PCB CNC Machine
$70 – $150pressure foot cup is a specialized, often cylindrical housing in a PCB drilling machine that stabilizes the board stack through downward pressure while simultaneously acting as a vacuum shroud to extract dust and heat away from the hole during high-speed spindle operations.
-
Pressure foot ring for PCB
$0.1 – $0.2pressure foot ring is a critical contact component in a CNC PCB drilling machine that applies downward pressure to the board stack, ensuring material flatness and stabilizing the workpiece against high-speed spindle vibrations.
-
Pressure foot slider for PCB
$5 – $50pressure foot slider is a low-friction, precision-machined component (often made of nylon) that guides the vertical movement of the pressure foot assembly, ensuring smooth, linear travel and stable clamping of the PCB stack during the drilling process.
-
Schmoll Tool Gripper for PCB CNC Machine
$150.00Schmoll Tool Gripper for pcb is used on Schmoll drilling machine to clamp the drill bits on PCB drilling process
Material: Alloy+coating
-
Tool gripper clamp drilling machine
$20.00tool gripper clamp for a drilling machine is a high-precision, often pneumatic, assembly designed to securely hold and rapidly exchange drill bits within a CNC system to ensure seamless automated production.
-
Tool pod for drill bit holder
$2.8 – $5tool pod for a drill bit holder is a high-precision receptacle within a CNC machine’s magazine that securely stores, protects, and aligns individual drill bits for rapid, automated tool exchanges.
